EV4T-TS "Thermal Transfer/Thermal Direct Label Printer"
Back to label machine home page
Ribbon and Label Sets
Add to Tracking
Product Number：
P0000EV4TS0000
Quantity：
- +
Price：
$ 0NTD / Station
Inventory：
3空值
Shipping Fee：
  • Purchase on the main island over 5,000 NT dollars: Free shipping.
  • For purchases under 5,000 NT dollars on the main island: Shipping fee of 120 NT dollars.
  • Additional charges apply for remote areas, offshore islands, and international shipping.
Warranty：

From the date of shipment by our company, the barcode printer comes with a 12-month warranty, excluding the print head. The print head is covered by a 3-month warranty or up to 30 kilometers, whichever comes first.

Products：
  • Resolution: 305dpi
  • Printing Width: 105.7mm
  • Printing Speed: Up to 101.6mm/second
  • Print Head: Flat Pressure
  • Interface: Centronics, Built-in Ethernet, USB 2.0
  • Media Alignment: Centered
  • Ribbon Replacement: Snap-in
  • Exterior Structure: ABS strong plastic integrated molding with a transparent window and LED display (in orange, red, and green)
  • Applicability: Suitable for small-scale printing with limited label type variations, ideal for scenarios with low-volume printing needs.
Specifications
  • An economical high-spec label printer that delivers high-quality printing results at a low cost. It's compact and space-saving, making it suitable for customers with low-volume printing needs.
  • Built-in Ethernet server interface, allowing flexibility in placement.
  • Easy operation with a top-opening design that saves operation space.

Specifications:

  • Printing Mode: Thermal Transfer/Thermal Direct
  • Resolution: 305dpi
  • Printing Width: 105.7mm
  • Printing Speed: Up to 101.6mm/second
  • Printing Length: 8-453.2mm
  • Maximum Paper Width: 112mm
  • Exterior Structure: ABS strong plastic integrated molding with a transparent window and LED display (orange, red, green)
  • Dimensions: 98mm (Width) x 258mm (Depth) x 173mm (Height) (excluding the external paper holder)
  • Weight: 2.4 Kg
Operating environment
  • Communication Interfaces: Centronics, Built-in Ethernet, USB Interface
  • Software: Compatible with BarTender Ultralite, which can be used on Windows 7 and above. It can be upgraded to Basic, Professional, or higher-level software (available for separate purchase).
  • Driver Support: Windows Drivers 2000/XP/7 or newer
  • Operating Temperature: +5°C to +40°C
  • Relative Humidity: 25% to 85%
  • Electrical Specifications: 100V-240V, 50/60Hz DC auto-switching power supply
  • Safety Certifications: SAA, OVE, CEBEC, CSA, DEMKO, FEI, UTE, VDE, NSAI, IMQ, METI, KEMA, NEMKO, AEE, SEMKKO, SEV, ASTA, BSI, UL, HAR, CCC
  • Manufacturing Country: China
Paper/Printer Ribbon Specifications
  • Paper Types: Continuous, Roll, Folded
  • Paper Width: 25.4mm to 112mm
  • Maximum Paper Roll Capacity (Outer Diameter): 168mm (with external paper roll holder)
  • Paper Roll Core: 76mm (with external paper roll holder)
  • Label Gap: 3mm
  • Carbon Ribbon Core Size: 12.7mm
  • Carbon Ribbon Length: 75-100M
  • Label Thickness: 0.06mm to 0.19mm
  • Minimum Label Height: 8mm
  • Carbon Ribbon Specifications: Outer Wound
  • Label Packaging: Inner Wound
  • Maximum Carbon Ribbon Width: 33.8mm to 110mm
Font/Graphic/Barcode Specifications
  • Controlled by software, it can support seven types of vector fonts, including Windows fonts and fonts like Hua Kang.
  • Supports JPG and BMP black and white image formats, including customer logos.
  • Text, barcodes, and graphics can be oriented in four directions: 0 degrees, 90 degrees, 180 degrees, and 270 degrees. They can be freely resized and rotated.
  • The software supports all one-dimensional and two-dimensional barcodes. For specific details on supported barcode types, please refer to the BarTender documentation.
Applicable Industries
  • Food Industry
  • Cosmetics Industry
  • Fashion and Apparel Industry
  • Libraries
  • Entertainment and Ticketing
  • Traditional Chinese Medicine Industry
  • Electrical Industry
  • Electronics Industry
  • Warehouse and Logistics
  • Transportation and Shipping
  • Retail Industry
  • Asset Management
  • And many more.
