B-EX4T2-HS12-QM-R "Thermal/Thermal Transfer Label Printer"
Product Number:
P0000EX4T20000
Quantity:
- +
Price:
$ 0NTD / Station
Inventory:
Shipping Fee:
  • Purchase on the main island over 5,000 NT dollars: Free shipping.
  • For purchases under 5,000 NT dollars on the main island: Shipping fee of 120 NT dollars.
  • Additional charges apply for remote areas, offshore islands, and international shipping.
Warranty:
  • Starting from the date of shipment from our company (inclusive), the barcode printer has a 12-month warranty (excluding the printhead).
  • Printhead warranty is for 3 months or 30 kilometers, whichever comes first.
Products:
  • Resolution: 600 dpi
  • Printing Width: 104 mm
  • Printing Speed: Up to 152.4 mm per second
  • Printhead: Flatbed
  • Communication Interfaces: Built-in Ethernet, USB 2.0
  • Media Alignment: Left-aligned
  • Ribbon Replacement Method: Push-in
  • Exterior Structure: Metal casing with a transparent window design
  • Applicability: The B-EX4T2 offers professional high-resolution printing with excellent print quality. Its sleek and aesthetically pleasing casing design is suitable for various office environments and harsh conditions, providing high-quality printing results.
Specifications

"The TOSHIBA B-EX4T2HS series label printer comes with unique new features that set it apart from the Tepy1 series. Unlike the Tepy1 series, the EX4T2HS's mechanical structure aligns paper to the left, offering a straightforward paper loading structure and support for both inner and outer roll ribbons. These new features make our brand-new flatbed industrial printer a competitive product in the market.

Regarding the connectivity interfaces, the EX4T2HS not only includes built-in Ethernet and USB interfaces but also offers a rich selection of optional connection ports, including parallel ports, serial ports, I/O expansion slots, RTC&USB HOST.

Fast, flexible, and highly reliable

Specifications:

  • Printing Modes: Both Thermal Transfer and Direct Thermal
  • Resolution: 600 dpi
  • Printing Width: 104 mm
  • Printing Speed: Up to 152.4 mm per second
  • Printing Length: 8 mm to 453.2 mm
  • Maximum Paper Width: 114 mm
  • Exterior Structure: Metal casing with a transparent window design
  • Dimensions: 278 mm W x 460 mm D x 310 mm H
  • Weight: 19 kg"
Operating environment
  • Communication Interfaces: Built-in Ethernet, USB 2.0
  • Software: BarTender Ultralite, compatible with Windows 7 and later versions. Upgrade options available to Basic/Professional or higher-level software (sold separately).
  • Driver Support: Windows Drivers for 2000/XP/7 and above
  • Operating Temperature: +5°C to +40°C, Relative Humidity: 25% to 85%
  • Electrical Specifications: 100V to 240V, 50/60Hz automatic switching power source
  • Safety Certifications: CE, UL
  • Country of Manufacture: Indonesia
Paper/Printer Ribbon Specifications
  • Paper Types: Continuous paper, gap paper, black mark paper, fanfold paper (external roll)
  • Paper Width: Up to 114 mm
  • Maximum Paper Roll Capacity (Outer Diameter): 200 mm
  • Paper Roll Core Diameter: 76 mm
  • Label Gap: 3 mm
  • Ribbon Core Size: 25.4 mm
  • Ribbon Length: 300 to 600 meters
  • Label Thickness: 0.06 mm to 0.19 mm
  • Black Mark Height: 2.0 mm to 10 mm
  • Minimum Label Height: 13 mm
  • Ribbon Specification: External Roll
  • Label Packaging: Inner Roll
  • Maximum Ribbon Width: 33.8 mm to 110 mm
Font/Graphic/Barcode Specifications
  • "Through software control, it can support seven types of vector fonts, including WINDOWS fonts and fonts like '華康'."
  • "It can support JPG and BMP black and white attribute image formats, including customer logos."
  • "Text, barcodes, and graphics can be oriented in four directions (0 degrees, 90 degrees, 180 degrees, and 270 degrees) and can be freely scaled, resized, and rotated."
  • "The software supports all one-dimensional and two-dimensional barcodes (For information on supported barcode types, please refer to the BarTender documentation)."
Applicable Industries
  • Manufacturing Industry
  • Automotive Parts Industry
  • Chemical Industry
  • Pharmaceutical Industry
  • Textile Industry
  • Electronics Industry
  • Cosmetics and Biotechnology Industry
  • Food Industry
  • Retail Industry
  • Transportation Industry
  • Government Agencies
  • And more.
Accessories
  •  Cutter
  •  Peeling Module
  •  Internal Rewinder
